| Board function | parameter | content |
| DAC | Chip model | PCM 5102 A |
| Way | The 2-way DAC, | |
| Sampling rate | 384 K sps | |
| Data bit | 32bit | |
| Digital interface | I2S | |
| Analog interface | dc coupling | |
| Analog output | Single-end output of ± 1 0 V; DC to 1 00KHz Support 1mHz, 1Hz, 1KHz, 100KHz sine wave output; Support any file of the waveform loop broadcast, file size support within 5 12 MB. |
|
| Output impedence | 1KΩ | |
| Junctor | BNC | |
| Absolute maximum input | ± 60 V without damage (peak) | |
| Simulation index | ||
| MCU part | Master processor | XC7Z 020 |
| Digital interface | 1-Gigabit Ethernet, RJ 45 connector | |
| Software | Windows Client, file download to the board card, loop play | |
| Board standard | ||
| Board size | 6 9X76.5mm | |
| Board weight | (Including heat sink) | |
| Board power supply | + 12V@500mA; | |
| Board power consumption | 6W | |
| working temperature | Industrial-40℃ to + 70℃ | |
